Overhead Separator : Self Cleaning Electromagnet Suspended Separator

Abbreviations and Conventions used Storewide

All Dimensions are in Metric Scale (mm); Conventions and abbreviations used throughout the Store:

L : Length | OD : Outer Dia | ID : Inner Dia | W : Width | H : Height | T : Thickness (also Height) | CS : Countersunk | G : Gauss

The terms Force or Pull Force are used interchangeably throughout the store and refer to the maximum observable or tested force against a 10mm thick grinded finish mild steel plate. The pull force will depreciate with thinner plates or sheets. The Pull force or Force is expressed in lbs, Kg or N.

[10N (Newtons) = approx 1 Kg = approx 2.2 lbs Pull Force] Use this text to share information about your product.

  • Driven by Electromagnetic field intensity to separate tramp.
  • Suitable for harsh environments and able to pick up tramp particles up to
    35 kgs.
  • Ideal for high intensity impurities that is continuously cleaned automatically.
  • Works continuously with reliable operation and requires continuous power
    supply to remain activated.

Datasheet
